Liberty CodeConnect™ Chargers
Standalone Smart Chargers
Built in partnership with leading EV charger manufacturers, Liberty CodeConnect™ is the turnkey solution for monetizable, access-controlled Level 2 charging — without the need for a network connection.
Simple to use. Simple to manage. Lowest cost.
- Lowest-Cost Solution for Managed Charging: One low payment per charger, per month.
- Patented Encryption: Eliminates the need for an internet connection to the charger.
- Powered by Trusted Brands: Liberty augments market leading EV chargers with CodeConnect technology.
- No Network or Gateway Setup Required: CodeConnect chargers are ready to deploy immediately.
- Simple Access Management: Sell access codes to the public or issue reusable PINs for frequent users.
Get your own CodeConnect
To connect with our team or purchase, use the form below.
Liberty CodeConnect™ Models
Liberty CodeConnect chargers are built on proven hardware in partnership with the leaders in Level-2 charging. Whatever your need, we have a CodeConnect Charger for you.
Liberty CodeConnect Wallbox Chargers
Built on Wallbox Pulsar Plus chargers for your guests, employees, customers or residents to enjoy using every day.
- Attractive and user friendly design: Add a modern touch to your parking area
- Ideal for light passenger vehicles: 40 and 48 Amp options
- Compact & Adaptable: Designed for flexible installation, supporting both wall or pedestal mounting options
Liberty CodeConnect Enphase Chargers:
Built on the the Enphase CS-100 for demanding applications in fleet and medium-heavy vehicle applications.
- Industrial grade: Rugged cast enclosure can take a beating for years and years of dependable service
- High power: Up to 19.2kW continuous charging power
- Advanced Safety Features: The CS-100 includes essential safety protocols such as integrated short-circuit protection (5,000 RMS Symmetrical Amps at 240 VAC) and auto-resetting ground fault protection (CCID 20 mA)
General Specifications:
| CodeConnect™ Wallbox Chargers | CodeConnect™ Enphase 100 | ||
| Model | LP-CC-WBP-040 | LP-CC-WBP-048 | LP-CC-ENC-100 |
| Maximum Output Current | 40 A continuous / 9.6 kW | 48 A continuous / 11.5 kW | 80 A continuous / 19.2 kW |
| Enclosure Dimensions | 7.9"H x 7.8"W x 3.9"D | 17"H x 22"W x 12"D | |
| Operating/Storage Temperature | -22ºF to 104ºF | -40ºF to 122ºF | |
| Mounting Options | Wall or pedestal mounted | ||
| EVSE Circuit Voltage | 240/208 V (Level 2), 60 Hz | ||
| Input voltage frequency | 50/60 Hz | ||
| Enclosure Type | NEMA 4, Indoor/Outdoor | ||
| Access Control Options | Keypad, Phone App, Website | ||
| Wiring Configuration | Hardwired | ||
| Warranty | 3 Years | ||
| Cable | |||
| Cable/Connector Type | SAE J1772 | ||
| Charging Cable Length | Pre-wired 25 ft (7.62 m) | ||
| Pedestal | |||
| Pedestal Dimensions | 58.98"H x 8.46"W | 52"H x 17"W x 10"D † | |
| Safety & Standards | |||
| Codes and Standards | UL 2594, UL 2231 | UL 2594, UL 2251, UL 2231-1 | |
| EMC Compliance | FCC Part 15 Class B | ||
| Short-circuit Protection | Integrated CCID20 (Charge current interruption device at 20mA) | 5,000 RMS Symmetrical Amps at 240 VAC | |
| Ground Fault Detection | Ground monitoring circuit, UL 2231 | Ground fault protection integral, CCID 20 mA, auto reset | |
| ENERGY STAR® Certification | Yes | ||
